overall weight    3650Kg
bucket capacity    0.2m³
engine model    Changchai 490
rotary /walking motor    Italy JK
pump    Plunger pump
overall length    4600mm
overall width    1700mm
overall height    2400mm
Turning radius of platform    1170mm
track length    2175mm
track width    300mm
arm length    1230mm
ground clearance    260mm
Height of moving arm end    2380mm
Platform Width    1550mm
engine backcover height    885mm
Platform ground clearance    577mm

Machine parameters
engine power    34KW
Number of cylinders    2400r/min
Pressure of hydraulic system    22MPa
Climbing slope    35°
Grounding pressure    34.8kpa
walking speed    2.7/4.6Km/h
Max. traction    55.6KN
Platform turning speed    9-11rmp

Working range
Max.digging height    4500mm
Max. dump clearance    3050mm
Max.digging depth    3100mm
Max.digging radius    4630mm
Max. horizontal mining distance    4730mm
Max. shovel depth    1820mm
Max. elevation of bulldozer    350mm
