overall weight    1960Kg
bucket capacity    0.06m³
engine power    14.7KW
speed    2200r/min
Pressure of hydraulic system    18MPa
Climbing slope    30°
Grounding pressure    32kpa
walking speed    2.5-4.5Km/h
Max. traction    15KN
Platform turning speed    13rmp
Maximum Digging Force    15KN
Max.digging height    3400mm
Max. dump clearance    2160mm
Max.digging depth    2050mm
Max.digging radius    3600mm
Max. horizontal mining distance    2950mm
Rear radius of rotation    1760mm
Max. shovel depth    220mm
Max. elevation of bulldozer    250mm
boom length    1860mm
arm length    940mm
bucket size    480mm
Machine configure    Overall size
overall length    3400mm
overall width    1000-1300mm
overall height    2200mm
Turning radius of platform    1760mm
track length    1650mm
track width    250mm
ground clearance    245mm
Height of moving arm end    1450mm
Platform Width    980mm
engine backcover height    650mm
Platform ground clearance    490mm
